80*100mm Woven wire mesh gabions / hot-dipped galvanized gabion
wire mesh
Product Description:
Gabion is made of twisted hexagonal opening steel mesh with the
type 8x10 mesh. The diameter of the wire mesh has normally 3 types:
2.2, 2.7 or 3.0 mm, which is filled with natural stone for river,
hill protection or construction, Gabions are enviroment friendly
and cost effective when compared to other options. The inherent
advantages of cost and the fact that Gabions withstand the rigors
of the enviroment for very long periods of time have made the use
widespread.
Technical Specifications:
Gabions sizes: 2m x 1m x 1m, 3m x 1m x 1m, 4m x 1m x 1m, 2m x 1m x
0.5m, 4m x 1m x 0.5m. Custom orders available.
Materials: Finish can be hot-dipped galvanized, galvanized aluminum
alloy or PVC coated, etc.
| Specification of Hexagonal Wire Netting |
| spec. of wire mesh | wire diameter | max. mesh width | | mesh no | mesh size | galv.wire | pvc coated wire | - | | 2-1/2" | 60x80 mm | BWG12 (2.80mm) | 4.0mm | 3200 mm | | 3" | 80x100 mm | BWG11 (3.00mm) | 4.0mm | 4000 mm | | 4" | 100x120mm | BWG11 (3.00mm) | 4.0mm | 4000 mm |
|
advantages of gabion wire mesh and rock mattresses include:
Durability
Our PVC coated wire gabions and mattresses are particularly well
suited for an extended life in harsh and corrosive environments.
Strength and flexibility
rock-mattresses, and rock fall netting are constructed from
double-twist hexagonal woven mesh. This provides inherent strength
and flexibility. Also, if a wire is cut or broken the mesh cannot
"unravel".
Porosity
Gabion and rock-mattress structures are porous to prevent build up
of hydrostatic pressure and are able to withstand differential
settlement.
Gabions application:
Gabions have been around for many years internationally and have a
wide range of uses, as beow:
Building blocks of gravity walls
Forming of gravity walls
Reinforced structure (a combination of reinforcing wire mesh
containers)
Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil
Protection engineering of seaside area.
Packing & Delivery:
Packing Details: In pallet or in bundle, as buyer's requirement.
Delivery Details: 5-10 Days after received the deposit by TT,
according to buyer's quantity.
We can offer a range of wire diameters to suit the application.
