Welded mesh gabions for bastion barrier / flood control bastion
barrier
Product Description:
Bastion barrier is a solid and high strength structure, which is
widely used in the itary defense and flood controlling
applications. It can protect troops and civilian personnel from
attacks and intruders, it can defend the bullet and gunfire out of
the base.
The structure of bastion barrier is siar as the welded gabion,
which is connected by the spiral wires. The filling material of
bastion barrier is commonly sands. The welded gabions are lined
with heavy duty non-woven polypropylene geotexitile to prevent
filling materials from leaking out from the large opening.
Bastion barrier has standard and recoverable types according to
different structure. As we all know, though the installation of
bastion barrier is easy and fast, but when it is filling with sands
or stones, the uninstallation may cost several time and
efforts.besides, the war is tight, it they are leaved there, it may
destroy the environment, so we have developed a new type of
products, named as recoverable bastion barrier. Just removing one
joint pin and the filling materials flowing out from the bastion
barrier unit. In this way, the bastion barrier can be recovered in
a simple, fast way. Additional, the bastion barrier can be folded
and take another itary base to save cost and protect the
environments.
| Item | Height | Width | Length | cells |
| 01 | 2' | 2' | 4' | 2 |
| 02 | 2' | 2' | 10' | 5 |
| 03 | 3'3" | 2'6" | 30' | 9 |
| 04 | 3'3" | 3'3" | 32'9" | 10 |
| 05 | 3'3" | 5' | 32'9" | 6 |
| 06 | 4 | 1' | 4' | 2 |
| 07 | 4'6" | 3'6" | 32'9" | 9 |
| 08 | 4'6" | 4' | 32'9" | 9 |
| 09 | 5'6" | 2' | 10' | 5 |
| 10 | 7' | 3'6" | 108' | 30 |
| 11 | 7'3" | 5' | 100' | 20 |
| 12 | 7'3" | 7' | 91' | 15 |
| 13 | 9' | 3'6" | 10'5" | 6 |
Material: electric galvanized, hot dipped galvanized or Galfan
coated steel wire.
Wire diameter: 3 mm - 5 mm.
Mesh opening: 2" × 2", 3" × 3", 4" × 4".
Geotextile color: white, gray, green, sand and other colors.
