| Commonly specifications of rockfall barrier system |
| Item | Net size | Supporting rope | Upper anchor rope | Anchor rope | Sewing rope | Loading capacity |
| RX-025 | Wire diameter: 8 mm.
Mesh size: 250 mm × 250 mm | 12 mm double steel wire rope.
Each spacer has 3 decompression rings | 16 mm single steel wire rope.
1 decompression ring | 12 mm single steel wire rope | 8 mm | ≤ 250 kJ |
| RX-050 | Wire diameter: 8 mm. Mesh size: 200 mm × 200 mm | 16 mm double steel wire rope.
Each spacer has 6 decompression rings | 14 mm single steel wire rope.
1 decompression ring | 16 mm single steel wire rope | 8 mm | ≤ 500 kJ |
| RX-075 | Wire diameter: 8 mm.
Mesh size: 150 mm × 150 mm | 18 mm double steel wire rope.
Each spacer has 10 decompression rings | 18 mm single steel wire rope.
2 decompression ring | 18 mm single steel wire rope | 8 mm | ≤ 750 kJ |
| RXI-025 | Circle quantity: 5.
Wire diameter: 3 mm.
Circle diameter: 300 mm. | 18 mm single steel wire rope | 16 mm single steel wire rope | 16 mm single steel wire rope | 8 mm | ≤ 250 kJ |
| RXI-050 | Circle quantity: 7.
Wire diameter: 3 mm.
Circle diameter: 300 mm. | 22 mm single steel wire rope | 18 mm single steel wire rope | 18 mm single steel wire rope | 8 mm | ≤ 500 kJ |
| RXI-075 | Circle quantity: 5.
Wire diameter: 3 mm.
Circle diameter: 300 mm | 16 mm double steel wire rope.
Each spacer and each metal column has 1 decompression rings.
Total is 6 decompression ring | 14 mm single steel wire rope.
1 decompression ring | 14 mm single steel wire rope | 8 mm | ≤ 750 kJ |
| RXI-100 | Circle quantity: 9.
Wire diameter: 3 mm.
Circle diameter: 300 mm. | 18 mm double steel wire rope.
Each spacer and each metal column has 1 decompression rings.
Total is 6 decompression ring | 16 mm single steel wire rope.
1 decompression ring | 16 mm single steel wire rope | 12 mm | ≤ 1000 kJ |
| RXI-150 | Circle quantity: 12.
Wire diameter: 3 mm.
Circle diameter: 300 mm. | 22 mm double steel wire rope.
Each spacer and each metal column has 1 decompression rings.
Total is 6 decompression ring. | 18 mm single steel wire rope.
1 decompression ring | 18 mm single steel wire rope | 12 mm | ≤ 1500 kJ |
| RXI-200 | Circle quantity: 19.
Wire diameter: 3 mm.
Circle diameter: 300 mm. | 18 mm double steel wire rope.
Each spacer and each metal column has 1/2 decompression rings.
Total is 8 decompression ring. | 18 mm single steel wire rope.
1 decompression ring | 18 mm single steel wire rope | 14 mm | ≤ 2000 kJ |
